Have photosensitive in double -face.design for single and double -face exposure Big frame , high
- Have photosensitive in double -face.design for single and double -face exposure
- Big frame , high precision,power saving
- Can exposure Dry film /wet film / solder mask
| Model | HC-01268R2W |
| light source type | UV-LED |
| Effective exposure size | 1240*680 mm |
| Substrate thickness | 0.075-10 mm |
| Line resolution | 75/75um |
| Exposure mode | Double exposure |
| Time of exposure | 10-35S |
| Suitable for | Dry film /wet film / solder mask |
| Exposure energy control | 0-100% adjustable / exposure time adjustable |
| cooling system | constant temperature water cooling |
| optical glass | Mylar +glass |
| vacuum degree | ≤ -90kap (adjustable) |
| power | 4.5kw |
| Machine size | 2450*1840*1700 mm |
| Machine weight | 1100Kg |
1. Trade Term: FOB Shenzhen USD by T/T in advance.
2. Discount is allowed against your quantity.
3. OED/OEM is accepted.
4. Delivery will be carried out by Express or your requirement.
5. Lead Time: 2~7 days after payment.
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: If machines, it will be about 10~15 working days. If spares, it will be about 2~3 working days after payment.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
