CNC 6 Spindles PCB Routing Machine R16KL
Product Specification:
- No. of Z axis：3 :
- No. of Spindle：6 :
- Processing area of each axis：650mm×830mm :
- XYZ axial movement stroke：670mm×925mm×55mm :
- Number of tools per axis：66 pcs :
- Routing diameter：φ0.6-φ3.175mm :
6-spindles pcb routing machine are the hot sale machines and its spares are imported from the famous brands such
Technical Features
- Natural-granite base
- CBD Electrical Connected Broken-tool Detection
- Real-time response, no missing-routing
- Tool change :Hitachi Or Euro method
- Optional: Automatic collet cleaning function
- Optional: Automatic pinning &De-ping function
| Model | PCB CNC Router_R16KL |
| No. of Z axis | 3 |
| No. of Spindle | 6 |
| Spindle Speed | 60k rpm / min (80k rpm) |
| Processing area of each axis | 630mm×8300mm |
| XYZ axial movement stroke | 650mm×925mm×55mm |
| Number of tools per axis | 66 pcs |
| Drilling diameter | φ0.5-φ6.35mm |
| Milling diameter | φ0.6-φ3.175mm |
| XY Axial max. movement speed | 35m/min |
| Ｚ Axial max. movement speed | 25m/min |
| System resolution ratio | 0.001mm |
| Positioning Accuracy | ±0.01mm |
| Repeatability Accuracy | ±0.005mm |
| Routing precision | ±0.05mm |
| Power requirements | 3P/380V/50Hz (±5%); 3KW |
| Compressed air requirement | 300L/min |
| Cooling water requirement | 18℃-25℃ |
| Environmental temperature | 20℃-25℃ |
| Ambient humidity | 50%-75% |
| Noise | ≤75dBA |
| Machine Size | 4700mm×2130mm×1600mm (L×W×H) |
| Accessories name | Specifications | Quantity | Brand |
| X axis- ball screw | 32×20-1260 | 1 | HIWIN(Taiwan, China) |
| Y axis- ball screw | 32×20-1260 | 1 | HIWIN(Taiwan, China) |
| Z axis- ball screw | 25×10-320 | 3 | HIWIN(Taiwan, China) |
| X axis-guide rail and slide block | 35×3960 | 2 | HIWIN(Taiwan, China) |
| Y axis-guide rail and slide block | 35×1480 | 2 | HIWIN(Taiwan, China) |
| Z axis-guide rail and slide block | 20×280 / 20×160 | 6/6 | HIWIN(Taiwan, China) |
| X/Y/Z axis-Servo Motor and Driver | 3KW; 3KW; 750KW | 1/1/3 | Delta(Taiwan, China) |
| X/Y/Z axis- Bearing | BS2047TN1/P4GB; 1205; 2047 | 4/2/6 | NSK(Japan) |
| Spindle | KL-60C—2E | 6 | KLKJ（China） |
